UL 752 Level 8 Specifications

Application

Most commonly used as a protection barrier against multiple shots from a military assault rifle, such as an M-14, and the like, with muzzle energy of 2519-3048 foot pounds (3416-4133J).

Nominal Thickness

1 – 7/16”

Nominal Weight

15.2 lbs per square foot

Minimum fps

2750

Velocity m/s

838

Grain

150

(g)

9.7

No. of Shots

3

UL 752 Paragraph

4.10

Ammunition Tested

150 grain (9.7 g) 7.62mm rifle full metal copper jacket with lead core, military ball, minimum velocity of 3080 fps (2750 mps)

Panel Sizes
  • 3' x 8'
  • 3' x 9'
  • 3' x 10'
  • 4' x 8'
  • 4' x 9'
  • 4' x 10'
  • 5' x 8'
  • 5' x 9'
  • 5' x 10'
Level 8 Bullet Resistant Performance Level
  • UL752 Standard for Bullet Resisting Equipment – Level 8 Paragraph 4.10
  • National Institute of Ballistic Standards NIJ0108.01 – Level III
  • One Hour Fire Rating Per ASTM E119-98
  • ASTM F1233-98 Standard Test Method for Forced Entry Testing of Materials/Assemblies
  • ASTM E 90-97, E 413-87, E 13320-90 Classifications for Sound Transmission Loss

Request Project Details


Additional Information

Other Products Available

ArmorCore® Bullet Resistant Fiberglass Panels are manufactured at all 8 Levels of UL752 Standards and NIJ0108.01 specifications.

UL 752 LEVEL 8 BENEFITS

  • Non-Spalling
  • Non-Conductive
  • Non-Ricocheting - captures the bullet
  • Provides protection against 7.62 NATO rounds
  • Protects multiple shots per square foot
  • Easy to install
  • Effective delay against forced entry
  • Low wicking – preventing buildup of mold
  • Nontoxic materials – no formaldehyde

*Does not meet standard under CA Prop 65.
